Adopting the JAPAN controller with P.I.D automatic control and sensity sensors in order to obtain precise temp conrtol accuracy up to ± 0.1℃ energy saving up to 35% than usually。

The control box and the temperature controller are separated, so that be able to extend the useful duration of electric part。

Seamless tube for heater,long life and hight efficiency。

Use stainless steel and hight pressure materials in internal piping material structure, low resistance,fast flow,high efficiency。

Complete with safety protection and error indication system。

The whole series is complete with auto air exhaustion,mold draing ,and various protective devices simple operation and stability。

Employing superb imported components with longer terms of service。






MODEL

UNIT

JSW-1012

JSW-2012

JSW-3012

JSW-1014

JSW-1518

JSW-1012E

JSW-2012E

JSW-3012E

JSW-1014E

JSW-1518E



CONTROL  RANGE

40~120

50~140

50~180



TEMP  CONTROL  ACCURACY

± 1 OR  ± 0.1



TEMP  CONTROL  METHOD



PROPORTIONAL  INTEGRAL  DERIVATIVE



POWER



3φ 220V380V  60HZ  OR  OTHER



MEDIUM



 WATER



COOLING  METHOD



 DIRECT  COOLING

 INDIRECT COOLING



HEATING  CAPACITY

KW

9

9

9

9

9



PUMP  POWER

HP

1

2

3

1

1.5



MAX  PUMP  FLOW

L/MIN

153

232

268

153

68



SYSTEM  PRESSURE

KG/c

4

6

6

4

10



POWER  SUPPLY

KW

9.75

10.5

11.2

9.75

10.1



COOLING  WATER  PIPE

INCH

12



HOT  WATER  PIPEING

INCH

38〞× 4OR  OTHER



L×W×H

CM

68×33×70

75×35×75

75×35×75



WEIGHT

KG

70

75

70

75

80

SPECIAL  DESIGN  UPON  REQUEST
